LW series decanting centrifuge is the fourth class solids control equipment in well drilling solids control. Using decanter principle to separate suspension liquid. According to rotary speed can be called middle speed decanting centrifuge, highspeed decanting centrifuge, and high speed variable frequency decanting centrifuge, mainly separate 2~7μm particle out.
|
Decanter Centrifuge |
||||
|
Model |
SCLW 450×842N |
SCLW 450×1250N |
SCLW 355×1250N |
SCLW 365G/VFD |
|
Bowl dia. |
450mm |
450mm |
355mm |
365mm |
|
Bowl length |
842mm |
1000mm |
1250mm |
1250 |
|
Bowl speed |
1800rpm |
2200rpm |
3200rpm |
0-3500rpm |
|
G-Force |
815 |
1220 |
2035 |
2500 |
|
Separation Point |
5-7μm |
5-7μm |
2-5μm |
2-5μm |
|
Main Drive |
22Kw-4p |
30Kw-4p |
30Kw-4p |
37Kw-4p |
|
Back Drive |
5.5Kw-4p |
7.5Kw-4p |
7.5Kw-4p |
7.5Kw-4p |
|
Max Capacity |
≤40m3/h |
≤60m3/h |
≤40m3/h |
≤40m3/h |
|
Weight |
2950kg |
3150kg |
2850kg |
2950kg |
|
Dimension |
2380×1560×1350mm |
2540×1560×1350mm |
2810×1490×1350mm |
3412×1600×1875 |
